Description of the data path
GUPPY Technical Manual V7.1.0
110
Format_7 Mode_0: sensor readout and color
In Format_7 Mode_0 controlling gain of the binned signals is done via
SmartView or via the advanced registers. That means there are four separate
gains, one for each binned component Cy+G, Mg+Ye, Mg+Cy and G+Ye.
Figure 59: Format_7 Mode_0: Binning for 1st field and 2nd field
Figure 60: Format_7 Mode_0: Sensor readout
G Mg G Mg G Mg G Mg
A1
G Mg G Mg
Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye
B1
Mg G Mg G Mg G Mg G
A2
Mg G Mg G
Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye
B2
G Mg G Mg G Mg G Mg
A3
G Mg G Mg
Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye
B3
Mg G Mg G Mg G Mg G
A4
Mg G Mg G
Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye Cy Ye
Sensor Bayer pattern 1st field 2nd field
G Mg
Y
R-Y B-Y
Cy Ye
Mg G
Y Y R-Y B-Y
Cy Ye
1st field
Y R-Y B-Y
Y R-Y B-Y
Cy Ye
Y
R-Y B-Y
Y R-Y B-Y
Mg G
Cy Ye
Y
G Mg
2nd field
