Configuration of the camera
GUPPY Technical Manual V7.1.0
252
Video mode control and status registers for
Format_7
Quadlet offset Format_7 Mode_0
The quadlet offset to the base address for Format_7 Mode_0, which can be
read out at F0F002E0h (according to
Table 101: Frame rate inquiry register
on page 232) gives 003C2000h.
4 x 3C2000h = F08000h so that the base address for the latter ( Table 108:
Format_7 control and status register on page 252) equals to
F0000000h + F08000h = F0F08000h.
Quadlet offset Format_7 Mode_1
The quadlet offset to the base address for Format_7 Mode_1, which can be
read out at F0F002E4h (according to
Table 101: Frame rate inquiry register
on page 232) gives 003C2400h.
4 x 003C2400h = F09000h so that the base address for the latter ( Table 108:
Format_7 control and status register on page 252) equals to
F0000000h + F09000h = F0F09000h.
Format_7 control and status register (CSR)
Offset Name Notes
000h MAX_IMAGE_SIZE_INQ Acc. to IIDC V1.3
004h UNIT_SIZE_INQ Acc. to IIDC V1.3
008h IMAGE_POSITION Acc. to IIDC V1.3
00Ch IMAGE_SIZE Acc. to IIDC V1.3
010h COLOR_CODING_ID See note
014h COLOR_CODING_INQ Acc. to IIDC V1.3
024h
.
.
033h
COLOR_CODING_INQ Vendor Unique Color_Coding
0-127 (ID=128-255)
ID=132 ECCID_MONO12
ID=136 ECCID_RAW12
ID=133 Reserved
ID=134 Reserved
ID=135 Reserved
See Chapter Packed 12-Bit Mode
on page 153.
034h PIXEL_NUMBER_INQ Acc. to IIDC V1.3
038h TOTAL_BYTES_HI_INQ Acc. to IIDC V1.3
03Ch TOTAL_BYTES_LO_INQ Acc. to IIDC V1.3
Table 108: Format_7 control and status register
