Description of the data path
GUPPY Technical Manual V7.1.0
160
Figure 94: Bayer pattern of Guppy F-036C
Figure 95: Bayer pattern of Guppy F-503C
Pixel (2,9)
Column readout direction
Row readout direction
Pixel (2,9)
Column readout direction
Row read
ou
t dir
ection
