Configuration of the camera
GUPPY Technical Manual V7.1.0
255
0xF1000270 FRAMEINFO Not supported
0xF1000274 FRAMECOUNTER Not supported
0xF1000280 HDR_CONTROL High dynamic range mode (only Guppy F-036)
see Chapter HDR (high dynamic range) (GUPPY F-036
only) on page 154
0xF1000284 KNEEPOINT_1
0xF1000288 KNEEPOINT_2
0xF100028C KNEEPOINT_3
0xF1000298 DEFECT_PIXEL_CORRECTION Defect pixel correction (only Guppy F-503)
see Table 120: Advanced register: Defect pixel correction
on page 268
0xF100029C
0xF10002A0
0xF1000300 IO_INP_CTRL1 see Table 22: Input configuration register on page 80
0xF1000304 IO_INP_CTRL2 only Guppy board level cameras
see Table 22: Input configuration register on page 80 0xF1000308 IO_INP_CTRL3
0xF100030C IO_INP_CTRL4
0xF1000320 IO_OUTP_CTRL1 see Table 28: Advanced register: Output control on page
86
0xF1000324 IO_OUTP_CTRL2
0xF1000328 IO_OUTP_CTRL3
0xF100032C IO_OUTP_CTRL4 only Guppy board level cameras
see Table 28: Advanced register: Output control on page
86
0xF1000340 IO_INTENA_DELAY see Table 121: Advanced register: Delayed Integration
Enable (IntEna) on page 271
0xF1000360 AUTOSHUTTER_CTRL see Table 122: Advanced register: Auto shutter control
on page 271
0xF1000364 AUTOSHUTTER_LO
0xF1000368 AUTOSHUTTER_HI
0xF1000370 AUTOGAIN_CTRL see Table 123: Advanced register: Auto gain control on
page 272
0xF1000390 AUTOFNC_AOI see Table 124: Advanced register: Autofunction AOI on
page 273
0xF1000394 AF_AREA_POSITION
0xF1000398 AF_AREA_SIZE
0xF1000400 TRIGGER_DELAY see Table 125: Advanced register: Trigger Delay
Advanced CSR on page 274
0xF1000410 MIRROR_IMAGE See Table 126: Advanced register: Mirror on page 275
0xF1000510 SOFT_RESET see Table 127: Advanced register: Soft reset on page 276
0xF1000550 USER PROFILES see Table 128: Advanced register: user profiles on page
277
Register Register name Remarks
Table 109: Advanced registers summary
