Introduction
GUPPY Technical Manual V7.1.0
17
continued from last page
V7.1.0 07.05.09 All advanced registers in 8-digit format beginning with 0xF1...
in Chapter
Advanced features (AVT-specific) on page 254ff.
Firing a new trigger while IntEna is still active can result in
missing image (not image corruption): see
Caution on page
88.
Revised Chapter White balance on page 114ff.
New Features: Guppy F-503:
• Defect pixel correction in Chapter Defect pixel correction
(only Guppy F-503B/C) on page 133 and Table 120:
Advanced register: Defect pixel correction on page 268
• More gain steps in Table 42: Manual gain range of the var-
ious GUPPY types (CCD and CMOS) on page 123
• Global reset release shutter in Chapter Electronic rolling
shutter (ERS) and global reset release shutter (GRR) (only
Guppy F-503)
on page 169
• Format_7 mode mapping in Chapter Binning and sub-sam-
pling access (only Guppy F-503) on page 151ff. and Chap-
ter Format_7 mode mapping (only Guppy F-503) on page
280f.
• Description of Trigger_Mode_0 with electronic rolling
shutter and global reset release shutter in Chapter
Trigger
modes on page 170ff.
• Changing between electronic rolling shutter (ERS) and
global reset release shutter (GRR) in
Table 133: Advanced
register: Global reset release shutter on page 282
• Max. exposure time in Chapter Extended shutter on page
264
Changed sensor name from Micron to Micron/Aptina in Table
9: Specification Guppy F-036B/C on page 33
Changed sensor name from Micron to Micron/Aptina in Table
18: Specification Guppy F-503B/C on page 51
Changed sensor name from Micron to Micron/Aptina in Chapter
HDR (high dynamic range) (GUPPY F-036 only) on page 154ff.
Changed sensor name from Micron to Micron/Aptina in Chapter
Controlling image capture on page 167
to be continued on next page
Version Date Remarks
Table 1: Document history
