Configuration of the camera
GUPPY Technical Manual V7.1.0
232
Inquiry register for video frame rate and base
address
19Ch V_MODE_INQ
(Format_7)
Mode_0 [0] Format_7 Mode_0 Mono8
RAW8
Mode _1 [1] Format_7 Mode_1
Mode _2 [2] Format_7 Mode_2
Mode _3 [3] Format_7 Mode_3
Mode _4 [4] Format_7 Mode_4
Mode _5 [5] Format_7 Mode_5
Mode _6 [6] Format_7 Mode_6
Mode _7 [7] Format_7 Mode_7
- [8..31] Reserved (zero)
Note

GUPPY cameras do not deliver color formats. Therefore
Mono8 corresponds to RAW8.
Both formats are supported to allow compatibility with IIDC
V1.31 and with other camera models.
Offset Name Field Bit Description
200h V_RATE_INQ
(Format_0, Mode_0)
FrameRate_0 [0] Reserved
FrameRate _1 [1] Reserved
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] 120 fps (v1.31)
FrameRate _7 [7] 240 fps (v1.31)
- [8..31] Reserved (zero)
Table 101: Frame rate inquiry register
Offset Name Field Bit Description Supported
Table 100: Video mode inquiry register
