Configuration of the camera
GUPPY Technical Manual V7.1.0
260
0xF1000044 ADV_INQ_2 Input_1 [0]
--- [1] Reserved
--- [2] Reserved
--- [3..7] Reserved
Output_1 [8]
Output_2 [9]
Output_3 [10]
--- [11..15] Reserved
IntEnaDelay [16]
--- [17..23] Reserved
Output 1 PWM [24] Board level only
Output 2 PWM [25] Board level only
Output 3 PWM [26] Board level only
Output 4 PWM [27] Board level only
--- [28..31] Reserved
0xF1000048 ADV_INQ_3 Camera Status [0]
Max Isosize [1]
--- [2] Reserved
Format_7 Mode Mapping [3]
Auto Shutter [4]
Auto Gain [5]
Auto FNC AOI [6]
--- [7..8] Reserved
Low Noise Binning [9]
AFE References [10]
Global Reset Release Shutter [11]
Defect Pixel Correction [12]
--- [13..31] Reserved
0xF100004C ADV_INQ_4 --- [0..3] Reserved
White Balance [4..31] Guppy interlaced
only
Register Name Field Bit Description
Table 112: Advanced register: Advanced feature inquiry
