Camera interfaces
GUPPY Technical Manual V7.1.0
82
With IIDC V1.31 there is a standard CSR at register F0F00534/834h to control
a delay up to FFFh x timebase value. The following table explains the Inquiry
register and the meaning of the various bits.
Register Name Field Bit Description
0xF0F00534 TRIGGER_DELAY_INQUIRY Presence_Inq [0] Indicates presence of this
feature (read only)
Abs_Control_Inq [1] Capability of control with
absolute value
--- [2] Reserved
One_Push_Inq [3] One-push auto mode (Con-
trolled automatically by the
camera once)
Readout_Inq [4] Capability of reading out the
value of this feature
ON_OFF [5] Capability of switching this
feature ON and OFF
Auto_Inq [6] Auto Mode (Controlled auto-
matically by the camera)
Manual_Inq [7] Manual Mode (Controlled by
user)
Min_Value [8..19] Min. value for this feature
(1 µs)
Max_Value [20..31] Max. value for this feature
Table 24: Trigger_Delay_Inquiry register
