Configuration of the camera
GUPPY Technical Manual V7.1.0
245
530h
TRIGGER_INQ
Presence_Inq
[0]
Indicates presence of this
feature (read only)
Abs_Control_Inq
[1]
Capability of control with
absolute value
-
[2..3
Reserved
Readout_Inq
[4]
Capability of reading out the
value of this feature
ON_OFF
[5]
Capability of switching this
feature ON and OFF
Polarity_Inq
[6]
Capability of changing the
polarity of the rigger input
-
[7..15]
Reserved
Trigger_Mode0_Inq
[16]
Presence of Trigger_Mode 0
Trigger_Mode1_Inq
[17]
Presence of Trigger_Mode 1
Trigger_Mode2_Inq
[18]
Presence of Trigger_Mode 2
Trigger_Mode3_Inq
[19]
Presence of Trigger_Mode 3
-
[20..30]
Reserved
Trigger_Mode15_Inq [31]
Presence of Trigger_Mode 15
534h
TRIGGER_DELAY_INQUIRY Presence_Inq
[0]
Indicates presence of this
feature (read only)
Abs_Control_Inq
[1]
Capability of control with
absolute value
-
[2]
Reserved
One_Push_Inq
[3]
One-push auto mode Con-
trolled automatically by the
camera once)
Readout_Inq
[4]
Capability of reading out the
value of this feature
ON_OFF
[5]
Capability of switching this
feature ON and OFF
Auto_Inq
[6]
Auto Mode (Controlled auto-
matically by the camera)
Manual_Inq
[7]
Manual Mode (Controlled by
user)
Min_Value
[8..19]
Min. value for this feature
Max_Value
[20..31]
Max. value for this feature
538 .. 57Ch
Reserved for other FEATURE_HI_INQ
580h
ZOOM_INQ
Always 0
Register
Name
Field
Bit
Description
Table 104: Feature elements inquiry register
