Configuration of the camera
GUPPY Technical Manual V7.1.0
256
0xF1000580 LOW_NOISE_BINNING see Chapter Low noise binning mode (2 x and 4 x bin-
ning) (only Guppy F-503) on page 281
0xF1000800 IO_OUTP_PWM1 Guppy board level cameras only
see Table 31: PWM configuration registers on page 90 0xF1000804 IO_OUTP_PWM2
0xF1000808 IO_OUTP_PWM3
0xF100080C IO_OUTP_PWM4
0xF1000FFC GPDATA_INFO see Table 134: Advanced register: GPData buffer register
on page 283
0xF1001000
…
0xF10017FC
GPDATA_BUFFER
Note

Advanced features should always be activated before access-
ing them.
Note

• Currently all registers can be written without being
activated. This makes it easier to operate the camera
using Directcontrol.
• AVT reserves the right to require activation in future
versions of the software.
Register Register name Remarks
Table 109: Advanced registers summary
