ALLIED Vision Technologies Guppy F-503 User Manual
Page 236
Configuration of the camera
GUPPY Technical Manual V7.1.0
236
22Ch
V_RATE_INQ (Format_1,
Mode_3)
FrameRate_0
[0]
1.875 fps
FrameRate _1
[1]
3.75 fps
FrameRate _2
[2]
7.5 fps
FrameRate _3
[3]
15 fps
FrameRate _4
[4]
30 fps
FrameRate _5
[5]
60 fps
FrameRate _6
[6]
120 fps (v1.31)
FrameRate _7
[7]
240 fps (v1.31)
-
[8..31]
Reserved (zero)
230h
V_RATE_INQ
(Format_1, Mode_4)
FrameRate_0
[0]
1.875 fps
FrameRate _1
[1]
3.75 fps
FrameRate _2
[2]
7.5 fps
FrameRate _3
[3]
15 fps
FrameRate _4
[4]
30 fps
FrameRate _5
[5]
60 fps
FrameRate _6
[6]
120 fps (v1.31)
FrameRate _7
[7]
240 fps (v1.31)
-
[8..31]
Reserved (zero)
234h
V_RATE_INQ
(Format_1, Mode_5)
FrameRate_0
[0]
1.875 fps
FrameRate _1
[1]
3.75 fps
FrameRate _2
[2]
7.5 fps
FrameRate _3
[3]
15 fps
FrameRate _4
[4]
30 fps
FrameRate _5
[5]
60 fps
FrameRate _6
[6]
120 fps (v1.31)
FrameRate _7
[7]
240 fps (v1.31)
-
[8..31]
Reserved (zero)
Offset
Name
Field
Bit
Description
Table 101: Frame rate inquiry register
