ALLIED Vision Technologies Guppy F-503 - Manual (Page 164)

Description of the data path
GUPPY Technical Manual V7.1.0
164
0004h SERIAL_CONTROL_REG RE [0] Receive enable
RD: Current status
WR: 0: disable
1: Enable
TE [1] Transmit enable
RD: Current status
WR: 0: disable
1: Enable
- [2..7] Reserved
SERIAL_STATUS_REG TDRD [8] Transmit data buffer ready
Read only
0: not ready
1: ready
- [9] Reserved
RDRD [10] Receive data buffer ready
Read only
0: not ready
1: ready
- [11] Reserved
ORER [12] Receive data buffer overrun error
Read: current status
0: no error
WR: 0 to clear status
(1: Ignored)
FER [13] Receive data framing error
Read: current status
0: no error
WR: 0 to clear status
(1: Ignored)
PER [14] Receive data parity error
Read: current status
0: no error
WR: 0 to clear status
(1: Ignored)
- [15..31] Reserved
Offset Name Field Bit Description
Table 56: Serial input/output control and status register (SIO CSR)
