Specifications
GUPPY Technical Manual V7.1.0
31
Guppy F-033B/C BL (board level)
Feature Specification
Image device Type 1/3 (diag. 6 mm) progressive scan SONY IT CCD ICX424AL/AQ
with HAD microlens
Effective chip size 4.9 mm x 3.7 mm
Cell size 7.4 µm x 7.4 µm
Lens mount C-Mount: 17.526 mm (in air), Ø 25.4 mm (32 tpi), mechanical
flange back to filter distance: 9.5 mm
(see
Figure 29: Guppy C-Mount dimensions on page 71)
CS-Mount: 12.526 mm (in air), Ø 25.4 mm (32 tpi), mechanical
flange back distance: 8 mm
(see
Figure 30: Guppy CS-Mount dimensions on page 72)
Picture size (max.) 656 x 494 pixels (Format_7 Mode_0)
ADC 14 bit
Frame rates 3.75 fps; 7.5 fps; 15 fps; 30 fps; 60 fps
variable frame rates in Format_7 up to 58 fps
Gain control Manual: 0-24 dB (0.035 dB/step); auto gain (select. AOI)
Shutter speed 129 µs … 67,108,864 µs (~67s); auto shutter (select. AOI)
External trigger shutter Trigger_Mode_0, Trigger_Mode_1, advanced feature:
Trigger_Mode_15 (bulk); trigger delay
Look-up table One, user programmable (10 bit  8 bit); gamma (0.5)
Smart functions • AGC (auto gain control), AEC (auto exposure control), LUT
(look-up table)
only color: AWB (auto white balance)
• 4 free configurable inputs/outputs with pulse width modula-
tion (PWM) for each, RS-232 port (serial port, IIDC V1.31)
Transfer rate 100 Mbit/s, 200 Mbit/s, 400 Mbit/s
Digital interface IEEE 1394a IIDC V1.3, two ports (daisy chain)
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 10-pin connector
Power consumption Less than 2 watt (@ 12 V DC)
Dimensions 35 mm x 35 mm (sensor board); 35 mm x 70 mm (main board); with-
out lens
Mass ~30 g (without lens mount adapter, without lens)
Operating temperature + 5 °C ... + 45 °C (without condensation)
Storage temperature - 10 °C ... + 60 °C ambient temperature (without condensation)
Table 8: Specification Guppy F-033B/C BL (board level)
