Configuration of the camera
GUPPY Technical Manual V7.1.0
253
040h
PACKET_PARA_INQ
See note
044h
BYTE_PER_PACKET
Acc. to IIDC V1.3
Note
•
For all modes in Format_7, ErrorFlag_1 and
ErrorFlag_2 are refreshed on each access to the
Format_7 Register.
•
Contrary to IIDC V1.3, registers relevant to Format_7
are refreshed on each access. The Setting_1 bit is
automatically cleared after each access.
•
When ErrorFlag_1 or ErrorFlag_2 are set and Format_7
is configured, no image capture is started.
•
Contrary to IIDC V1.3, COLOR_CODING_ID is set to a
default value after an INITIALIZE or reset.
•
Contrary to IIDC V1.3, the UnitBytePerPacket field is
already filled in with a fixed value in the
PACKET_PARA_INQ register.
Offset
Name
Notes
Table 108: Format_7 control and status register
