Video formats, modes and bandwidth
GUPPY Technical Manual V7.1.0
215
640 33.4 35.5
620 34.7 36.3
600 35.6 37.3
580 36.4 38.2
560 37.2 39.3
540 38.0 40.3
520 38.8 41.6
500 39.7 43.0
480 40.5 44.1
460 41.4 45.6
440 42.5 47.2
420 43.5 48.6
400 44.5 50.5
380 45.7 52.1
360 46.8 54.2
340 48.1 56.1
320 49.4 58.6
300 50.8 61.3
280 52.3 63.8
260 53.9 67.0
240 55.5 70.5
220 57.3 73.7
200 59.1 78.0
180 61.2 82.0
160 63.2 87.4
140 65.5 93.6
120 68.0 99.4
100 70.8 107.4
80 73.6 115.0
64 76.2 124.0
60 not available 126.0
30 not available 144.0
AOI height / pixel Frame rate / fps
Guppy F-080
Frame rate / fps
Guppy F-080 BL
Table 87: Frame rates GUPPY F-080 and board level versions
