Introduction
GUPPY Technical Manual V7.1.0
15
continued from last page
V6.2.0 15.08.08 Added cross-reference from upload LUT to GPDATA_BUFFER in
Chapter
Loading an LUT into the camera on page 132
Added Guppy F-146 with Mono8 (8-bit format) and Mono12/16
(12-bit format) in Chapter
Pixel data on page 93f. In 12-bit
mode the data output is MSB aligned (12 significant bits). In
16-bit mode the data output is MSB aligned (also 12 significant
bits).
Added detailed level values of I/Os in Chapter GUPPY (housing)
on page 76 and Chapter GUPPY (board level) on page 77.
Added little endian vs. big endian byte order in Chapter
GPDATA_BUFFER on page 283
Added RoHS in Chapter Declarations of conformity on page 24
Listed shutter speed with offset in Chapter Specifications on
page 29ff.
New measurement of IntEna signals, therefore new offsets in
Chapter
Exposure time (shutter) and offset on page 181f. and
in Figure 104: Data flow and timing after end of exposure
(Guppy F-038/044 also NIR) on page 186.
New photo of LED positions in Figure 35: Status LEDs on page
78
to be continued on next page
Version Date Remarks
Table 1: Document history
