Format_7 mode mapping (only Guppy F-503)
With Format_7 mode mapping it is possible to map special binning and sub-
sampling modes to F7M1..F7M7 (see
Figure 90: Mapping of possible Format_7
modes to F7M1...F7M7 on page 152
Additional Format_7 modes
Guppy F-503 has additional Format_7 modes. There are some special
Format_7 modes which aren’t covered by the IIDC standard. These special
modes implement binning and sub-sampling.
To stay as close as possible to the IIDC standard the Format_7 modes can be
mapped into the register space of the standard Format_7 modes.
There are visible Format_7 modes and internal Format_7 modes:
•
At any time only 8 Format_7 modes can be accessed by a host computer.
•
Visible Format_7 modes are numbered from 0 to 2 and 4 to 6.
•
Internal Format_7 modes are numbered from 0 to 2, 4 to 6, 8 to 10, 17
to 18, 20 to 22, 24 to 26.
Format_7 Mode_0 represents the mode with the maximum resolution of
the camera: this visible mode cannot be mapped to any other internal mode.
Register
Name
Field
Bit
Description
0xF1000580
F7MODE_MAPPING Presence_Inq
[0]
Indicates presence of this feature
(read only)
---
[1..31]
Reserved
0xF1000584
F7MODE_MAP_INQ F7MODE_00_INQ
[0]
Format_7 Mode_0 presence
F7MODE_01_INQ
[1]
Format_7 Mode_1 presence
...
...
...
F7MODE_31_INQ
[31]
Format_7 Mode_31 presence
0xF1000588
Reserved
---
---
---
0xF100058C
Reserved
---
---
---
0xF1000590
F7MODE_0
Format_ID
[0..31]
Format ID (read only)
0xF1000594
F7MODE_1
Format_ID
[0..31]
Format ID for Format_7 Mode_1
Def
ault: FFFFFFFF
0xF1000598
F7MODE_2
Format_ID
[0..31]
Format ID for Format_7 Mode_2
0xF100059C
F7MODE_3
Format_ID
[0..31]
Format ID for Format_7 Mode_3
0xF10005A0
F7MODE_4
Format_ID
[0..31]
Format ID for Format_7 Mode_4
0xF10005A4
F7MODE_5
Format_ID
[0..31]
Format ID for Format_7 Mode_5
0xF10005A8
F7MODE_6
Format_ID
[0..31]
Format ID for Format_7 Mode_6
0xF10005AC
F7MODE_7
Format_ID
[0..31]
Format ID for Format_7 Mode_7
Table 131: Advanced register: Format_7 mode mapping
