Configuration of the camera
GUPPY Technical Manual V7.1.0
234
210h V_RATE_INQ
(Format_0, Mode_4)
FrameRate_0 [0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] 120 fps (v1.31)
FrameRate _7 [7] 240 fps (v1.31)
- [8..31] Reserved (zero)
214h V_RATE_INQ
(Format_0, Mode_5)
FrameRate_0 [0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] 120 fps (v1.31)
FrameRate _7 [7] 240 fps (v1.31)
- [8..31] Reserved (zero)
218h V_RATE_INQ (Format_0,
Mode_6)
FrameRate_0
[0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] 120 fps (v1.31)
FrameRate _7 [7] 240 fps (v1.31)
- [8..31] Reserved (zero)
21Ch
…
21Fh
Reserved V_RATE_INQ_0_x (for other Mode_x of
Format_0)
Always 0
Offset Name Field Bit Description
Table 101: Frame rate inquiry register
