Every register is 32 bit (big endian) and implemented as follows (MSB = Most
Significant Bit; LSB = Least Significant Bit):
Example
This requires, for example, that to enable ISO_Enabled mode (see Chapter
ISO_Enable / free-run on page 187), (bit 0 in register 614h), the value
80000000 h must be written in the corresponding register.
Far left
Bit
0
Bit
1
Bit
2
...
Bit
30
Bit
31
MSB LSB
Table 93: 32-bit register
