Description of the data path
GUPPY Technical Manual V7.1.0
129
To configure this feature in control and status register (CSR):
Register
Name
Field
Bit
Description
0xF0F0081C
SHUTTER
Presence_Inq
[0]
Presence of this feature:
0: N/A
1: Available
Abs_Control
[1]
Absolute value control
O: Control with value in the Value field
1: Control with value in the Absolute value
CSR
If this bit=1, the value in the Value field will
be ignored.
-
[2..4]
Reserved
One_Push
[5]
Write 1: begin to work (self-cleared after oper-
ation)
Read:
1: in operation
0: not in operation
If A_M_Mode = 1, this bit will be ignored.
ON_OFF
[6]
Write: ON or OFF this feature
Read: read a status
0: OFF
1: ON
A_M_MODE
[7]
Write: set mode
Read: read current mode
0: MANUAL
1: AUTO
-
[8..19]
Reserved
Value
[20..31]
Read/Write Value
This field is ignored when writing the value in
Auto or OFF mode.
If readout capability is not available, reading
this field has no meaning.
Table 46: CSR: Shutter
Note
Minimum shutter time for interlaced models in Format_7
Mode_1 is limited to the duration time of one field
(33/25 ms) see description of Shutter (integration) param-
eter in
