Video formats, modes and bandwidth
GUPPY Technical Manual V7.1.0
196
Guppy F-080B / Guppy F-080C
and board level versions F-080B BL / F-080C BL
* : Color camera outputs RAW image, which needs to be converted outside of
camera.
Format Mode Resolution Color mode 60
fps 30
fps 15
fps 7.5
fps 3.75
fps 1.875
fps
0
0 160 x 120 YUV444
1 320 x 240 YUV422
2 640 x 480 YUV411
3 640 x 480 YUV422
4 640 x 480 RGB8
5 640 x 480 MONO8 x x* x x* x x* x x*
6 640 x 480 MONO16
1
0 800 x 600 YUV422
1 800 x 600 RGB8
2 800 x 600 MONO8 x x* x x* x x*
3 1024 x 768 YUV422
4 1024 x 768 RGB8
5 1024 x 768 MONO8 x x* x x* x x* x x*
6 800 x 600 MONO16
7 1024 x 768 MONO16
7
0 1032 x 778
1032 x 778
MONO8
Raw8
@30 fps
@30 fps
1
2
3
Table 78: Video formats Guppy F-080B / Guppy F-080C
