Camera interfaces
GUPPY Technical Manual V7.1.0
75
Camera I/O connector pin assignment
The camera I/O connector is designed for industrial use.
It provides:
•
access to the inputs and outputs on the camera
•
a serial interface
The following diagrams show the pinning as viewed in pin direction.
Signal
Pin
Pin
Signal
TPA+
6
1
TPA-
-
7
2
GND
TPB+
8
3
TPB-
-
9
4
Cable power
-
10
5
Cable shield
Table 19: Board level camera: IEEE 1394a pin assignment (FireWire connector 1)
Note
The part number of the appropriate straight I/O connector is:
•
HIROSE HR25-7TP-8S, AVT article number K7600503
AVT also supplies various I/O cables of different lengths, a
selection is listed below:
I/O cable, open 8-pin HIROSE female to open end, 2.0 m
K1200196
I/O cable, open 8-pin HIROSE female to open end, 5 m
K1200197
