Video formats, modes and bandwidth
GUPPY Technical Manual V7.1.0
218
The frame rates in the following table are measured directly at the output of
the camera. Compare with Chapter
How does bandwidth affect the frame
rate? on page 219.
AOI height / pixel Frame rate / fps
full width
Frame rate / fps
half width
Frame rate / fps
quarter width
1944 6.5 12.9 25.9
1600 7.8 15.7 31.4
1280 9.8 19.7 39.3
1024 12.3 24.6 49.2
800 15.8 31.4 62.7
640 19.7 39.3 78.0
480 26.2 52.4 104.5
320 39.3 78.0 152.3
240 52.4 104.5 197.5
120 104.5 207.7 355.5
Table 89: Frame rates GUPPY F-503 as function of AOI height and AOI width
(full/half/quarter)
Note

The minimum AOI of GUPPY F-503 is 64 x 64
(AOI width x AOI height).
The readout time for one row is not constant. It varies with
AOI width.
