6: Hardware Data Sheets and Instructions
Specification Value
Probe temperature range
-80 ° C to 80° C (reflects range of ruthenium complex in
the sol-gel matrix)
Connector SMA 905
Response time (without overcoat) <1 second
Compensation Temperature compensation only
Probe reconditioning Yes (FOXY-RECOV @ $100)
Re-calibration Required when probe is replaced or cleaned by autoclave
Probe lifetime 1 year
FOXY-T1000 Stainless-steel Fiber Optic Probe
with Light Shield
The FOXY-T1000 is a 1000- µm silica core, silica-clad fiber encased in a stainless-steel ferrule with a
screw-on tip. The 7" long probe has an outer diameter of 1/4" and is extremely rugged. The probe can
withstand pressure up to 3000 psi and temperature up to 80
° C. It is designed for use with the 600-µm
bifurcated optical fiber assembly.
See Oxygen Sensing Probes – General Information at the beginning of this chapter for information on
cleaning and sterilizing oxygen probes.
FOXY-T1000 Stainless Steel Probe with Light Shield
FOXY-AL300-000-02-0207 83
