6: Hardware Data Sheets and Instructions
FOXY-AL300 Aluminum-jacketed Fiber Optic
Probe
The FOXY-AL300 is a 300-µm aluminum jacketed fiber optic probe. The aluminum jacketing, which is
FDA approved, is designed for applications where extraordinary environmental performance is required.
Aluminum jacketed fibers do not weaken under stress (as ordinary fibers do) and have an extremely high
break strength. This extremely flexible and thin probe is 1 meter in length and is designed for use with the
BIF200-VIS/NIR 200-µm bifurcated optical fiber assembly.
See Oxygen Sensing Probes – General Information at the beginning of this chapter for information on
cleaning and sterilizing oxygen probes.
FOXY-AL300 Aluminum-Jacketed Fiber Optic Probe
FOXY-AL300 Specifications
Specification Value
Fiber core 300 µm silica
Fiber cladding Silica
Fiber jacketing Aluminum
Outer diameter 410 to 420 µm
Length 1 meter
Bending radius 2 cm
78 FOXY-AL300-000-02-0207
