6: Hardware Data Sheets and Instructions
Specification Value
Element type Platinum 100 ohm Single 3 Wire
Sheath material 316 SS
Light Sources
The LS-450 Blue LED is specially designed for use with the oxygen sensor. A linear voltage regulator
provides constant power to the LED. External power is supplied by a 12 Volt DC power transformer. The
LS-450 Blue LED pulsed source has a cable for external connection to the spectrometer. The R-LS-450
Blue LED is a card-mounted pulsed source for mounting in a spectrometer enclosure or 19" rack system.
Other light sources available include the USB-LS-395 Blue LED (395 nm) for direct attachment to the
USB4000 Spectrometer, the rack-mounted R-LS-395, and the rack-mounted Dual Blue 395 nm LED light
source.
LS-450 Blue LED Pulsed Light Source
The LS-450 Blue LED Pulsed Light Source is a compact, low-cost light-emitting diode that produces
pulsed or continuous spectral output at 470 nm -- the blue region -- for high-sensitivity emission
fluorescence measurements. The LS-450 excitation source can be combined with other sampling optics
for fluorescence applications.
LS-450 Blue LED Pulsed Light Source
94 FOXY-AL300-000-02-0207
