29. Electrical Characteristics

29.1

Absolute Maximum Ratings*

29.2

DC Characteristics

Operating Temperature.................................... -40

°

C to +85

°

C

*NOTICE:

Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.

Storage Temperature ..................................... -65°C to +150°C

Voltage on any Pin except RESET
with respect to Ground ................................-0.5V to V

CC

+0.5V

Voltage on RESET with respect to Ground......-0.5V to +13.0V

Maximum Operating Voltage ............................................ 6.0V

DC Current per I/O Pin ............................................... 40.0 mA

DC Current

V

CC

and GND Pins................................ 200.0 mA

T

A

= -40

°

C to +85

°

C, V

CC

= 2.7V to 5.5V (unless otherwise noted)

Symbol

Parameter

Condition

Min.

Typ.

Max. Units

V

IL

Input Low Voltage

Port B, C & D and XTAL1,
XTAL2 pins as I/O

-0.5

0.2V

CC

(1)

V

V

IH

Input High Voltage

Port B, C & D and XTAL1,
XTAL2 pins as I/O

0.6V

CC

(2)

V

CC

+0.5

V

V

IL1

Input Low Voltage

XTAL1 pin , External
Clock Selected

-0.5

0.1V

CC

(1)

V

V

IH1

Input High Voltage

XTAL1 pin , External
Clock Selected

0.7V

CC

(2)

V

CC

+0.5

V

V

IL2

Input Low Voltage

RESET pin

-0.5

0.2V

CC

(1)

V

V

IH2

Input High Voltage

RESET pin

0.9V

CC

(2)

V

CC

+0.5

V

V

IL3

Input Low Voltage

RESET pin as I/O

-0.5

0.2V

CC

(1)

V

V

IH3

Input High Voltage

RESET pin as I/O

0.8V

CC

(2)

V

CC

+0.5

V

V

OL

Output Low Voltage

(3)

(Port B, C & D and
XTAL1, XTAL2 pins as
I/O)

I

OL

= 10 mA, V

CC

= 5V

I

OL

= 6 mA, V

CC

= 3V

0.7

0.5

V

V

V

OH

Output High Voltage

(4)

(Port B, C & D and
XTAL1, XTAL2 pins as
I/O)

I

OH

= -10 mA, V

CC

= 5V

I

OH

= -8 mA, V

CC

= 3V

4.2

2.3

V

V

V

OL3

Output Low Voltage

(3)

(RESET pin as I/O)

I

OL

= 2.1 mA, V

CC

= 5V

I

OL

= 0.8 mA, V

CC

= 3V

0.9

0.7

V

V

V

OH3

Output High Voltage

(4)

(RESET pin as I/O)

I

OH

= -0.6 mA, V

CC

= 5V

I

OH

= -0.4 mA, V

CC

= 3V

3.8

2.2

V

V
