149
8209A–AVR–08/09
ATmega16M1/32M1/64M1
• Bit 1:0 – PSYNC0[1:0]: Synchronization Out for ADC Selection
Select the polarity and signal source for generating a signal which will be sent from module 0 to
the ADC for synchronization
.
18.16.3 POCRnSAH and POCRnSAL – PSC Output Compare SA Register
18.16.4 POCRnRAH and POCRnRAL – PSC Output Compare RA Register
18.16.5 POCRnSBH and POCRnSBL – PSCOutput Compare SB Register
Table 18-8. Synchronization Source Description in One Ramp Mode
PSYNCn1 PSYNCn0 Description
0 0 Send signal on leading edge of PSCOUTnA(match with OCRnSA)
0 1
Send signal on trailing edge of PSCOUTnA(match with OCRnRA or
fault/retrigger on part A)
1 0 Send signal on leading edge of PSCOUTnB (match with OCRnSB)
1 1
Send signal on trailing edge of PSCOUTnB (match with OCRnRB or
fault/retrigger on part B)
Table 18-9. Synchronization Source Description in Centered Mode
PSYNCn1 PSYNCn0 Description
0 0
Send signal on match with OCRnRA (during counting down of PSC). The
min value of OCRnRA must be 1.
0 1
Send signal on match with OCRnRA (during counting up of PSC). The
min value of OCRnRA must be 1.
1 0 no synchronization signal
1 1 no synchronization signal
Bit 7 6 5 4 3 2 1 0
– – – – POCRnSA[11:8] POCRnSAH
POCRnSA[7:0] POCRnSAL
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
Bit 7 6 5 4 3 2 1 0
– – – – POCRnRA[11:8] POCRnRAH
POCRnRA[7:0] POCRnRAL
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
Bit 7 6 5 4 3 2 1 0
– – – – POCRnSB[11:8] POCRnSBH
POCRnSB[7:0] POCRnSBL
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
