ATmega16M1/32M1/64M1
These 2 bits determine the gain of the amplifier 2.
The different setting are shown in
.
To ensure an accurate result, after the gain value has been changed, the amplifier input needs
to have a quite stable input value during at least 4 Amplifier synchronization clock periods.
• Bit 3 – AMPCMP2: Amplifier 2 - Comparator 2 connection
Set this bit to connect the amplifier 2 to the comparator 2 positive input. In this configuration the
comparator clock is adapted to the amplifier clock and AMP2TS2,AMP2TS1, AMP2TS0 bits
have no effect.
Clear this bit to normally use the Amplifier 2.
• Bit 2:0 – AMP2TS[2:0]: Amplifier 2 Clock Source Selection Bits
In accordance with the
, these 3 bits select the event which will generate the clock
for the amplifier 1. This clock source is necessary to start the conversion on the amplified
channel.
Table 22-12. Amplifier 2 Gain Selection
AMP2G[1:0]
Description
00
Gain 5
01
Gain 10
10
Gain 20
11
Gain 40
Table 22-13. AMP1 Clock Source Selection
AMP2TS[2:0]
Clock Source
000
ADC Clock/8
001
Timer/Counter0 Compare Match
010
Timer/Counter0 Overflow
011
Timer/Counter1 Compare Match B
100
Timer/Counter1 Overflow
101
PSC Module 0 Synchronization Signal (PSS0)
110
PSC Module 1 Synchronization Signal (PSS1)
111
PSC Module 2 Synchronization Signal (PSS2)
