1. Program the Fuse bits and Boot Lock bits before programming the LB1 and LB2.

2. “1” means unprogrammed, “0” means programmed

28.2

Fuse Bits

The ATmega16M1/32M1/64M1 has three Fuse bytes.

Table 28-4

-

Table 28-7

describe briefly

the functionality of all the fuses and how they are mapped into the Fuse bytes. Note that the
fuses are read as logical zero, “0”, if they are programmed.

Table 28-3.

Lock Bit Protection Modes

(1)(2)

.

BLB0 Mode

BLB02

BLB01

1

1

1

No restrictions for SPM or LPM accessing the Application
section.

2

1

0

SPM is not allowed to write to the Application section.

3

0

0

SPM is not allowed to write to the Application section, and LPM
executing from the Boot Loader section is not allowed to read
from the Application section. If Interrupt Vectors are placed in
the Boot Loader section, interrupts are disabled while executing
from the Application section.

4

0

1

LPM executing from the Boot Loader section is not allowed to
read from the Application section. If Interrupt Vectors are placed
in the Boot Loader section, interrupts are disabled while
executing from the Application section.

BLB1 Mode

BLB12

BLB11

1

1

1

No restrictions for SPM or LPM accessing the Boot Loader
section.

2

1

0

SPM is not allowed to write to the Boot Loader section.

3

0

0

SPM is not allowed to write to the Boot Loader section, and LPM
executing from the Application section is not allowed to read
from the Boot Loader section. If Interrupt Vectors are placed in
the Application section, interrupts are disabled while executing
from the Boot Loader section.

4

0

1

LPM executing from the Application section is not allowed to
read from the Boot Loader section. If Interrupt Vectors are
placed in the Application section, interrupts are disabled while
executing from the Boot Loader section.

Table 28-4.

Extended Fuse Byte

Extended Fuse Byte

Bit No

Description

Default Value

-

7

-

1 (unprogrammed)

-

6

-

1 (unprogrammed)

PSCRB

5

PSC Reset Behaviour

1 (unprogrammed)

PSCRVA

4

PSCOUTnA Reset Value

1 (unprogrammed)

PSCRVB

3

PSCOUTnB Reset Value

1 (unprogrammed)
