MEDIA CONTROL Submenus
119
MEDIA CONTROL Submenus
Print Intensity
This option specifies the level of thermal energy from the printhead to be used
for the type of media and ribbon installed.
Large numbers imply more heat (thermal energy) to be applied for each dot.
This has a significant effect on print quality. The print intensity and speed
must match the media and ribbon type to obtain the best possible print quality
and barcode grades.
The range is from -15 to +15.
The factory default is -3.
TOF Detect
Fault
3 Labels*
9 Labels
1 Label
Ticket Save
Mode
Disable*
Enable
TOF Adjust
Mode
Disable*
Enable
TOF Adjust
0.00 to 0.40 inches 3
Peel-Off
Mode
1
Fast*
Standard
Continuous
Mode
2
Standard*
Tear-Off
Tear-Strip Full
Cut Strip
MEDIA
CONTROL
(from page 118)
Notes:
* = Factory Default
Italicized items are available only when Admin User is set to Enable (in the PRINTER CONTROL
menu).
1 The Peel-Off option under Media Handling must be enabled for this menu to function.
2 The Continuous option under Media Handling must be enabled for this menu to function.
3
In increments of 0.01 inch.
4
Default is “Fine” on Small Label Printer.
5 Menu available only if Small Label Printer option is installed.
Ribbon
Calibrate 1
Standard*
Forward Only
Label,
Resolution 4, 5
Coarse*
Fine
Reverse
Speed
2 ips*
1 to 6 ips
