6.5.9. Audio Track Selection and Settings in the
Timeline
Introduction
In the timeline display, 6 tracks are visible: 1 video track and 5 audio tracks. For each
audio track, buttons are displayed on both sides of the displayed timeline track.
These buttons allow controlling some input and output settings used globally for each
track, although elements placed on a track can always be treated individually.
Track Name and Audio Type in the Timeline
The top track represents the video track.
The other tracks represent the audio tracks which can be used in the timeline. Up to 5
audio tracks are available.
The upper part of the Audio Track buttons show the name of the audio track facing the
button in the timeline display: from A1 to A5.
The lower part of the Audio Track buttons show the audio type of the timeline track:
