NetAtlas Workgroup Ethernet Switch Manager User’s Guide
59 Chapter 5 View
The following table describes the labels in this screen.
5.6 Multicast Status
View the IGMP multicast group membership information in the Multicast Status screen.
Click View > Multicast Status to display the screen as shown. Select a switch model in the
device list to display the multicast group membership information.
Figure 27 View: Multicast Status
Table 23 View: 802.1d: ARP Table
LABEL DESCRIPTION
Index This is the ARP table entry number.
IP Address This is the learned IP address of a device connected to a switch port with
corresponding MAC address below.
MAC Address This is the MAC address of the device with corresponding IP address above.
VID This is the VLAN group to which this ARP entry belongs.
Type This shows whether the MAC address is dynamic (learned by the switch) or static
(manually entered in the Static MAC Forwarding screen).
Polling The text box displays how often (in seconds) this screen refreshes. You may change
the refresh interval by typing a new number in the text box and then clicking the Apply
button.
Close Click Close to close the screen.
