NetAtlas Workgroup Ethernet Switch Manager User’s Guide
117 Chapter 13 System Configuration
The following table describes the labels in this screen.
13.6.1 Configuring an IP Interface
Follow the steps below to create a new IP interface.
1 In the Device Panel list, select a device and then right-click.
2 Click Configuration > System Configuration > IP Setup.
3 Click Add.
Table 51 System Configuration: IP Setup
LABEL DESCRIPTION
IP Setup
Default
Gateway
Enter the IP address of the default outgoing gateway in dotted decimal notation, for
example 192.168.1.254.
Domain Name
Server
DNS (Domain Name System) is for mapping a domain name to its corresponding IP
address and vice versa. Enter a domain name server IP address in order to be able to
use a domain name instead of an IP address.
Default
Management
Specify which traffic flow (In-Band or Out-of-band) the switch is to send packets
originating from itself (such as SNMP traps) or packets with unknown source.
Select Out-of-band to have the switch send the packets to the management port
labelled MGMT. This means that device(s) connected to the other port(s) do not
receive these packets.
Select In-Band to have the switch send the packets to all ports except the
management port (labelled MGMT) to which connected device(s) do not receive these
packets.
Management IP Address
Use these fields to set the settings for the out-of-band management port.
IP Address Enter the out-of-band management IP address of your switch in dotted decimal
notation. For example, 192.168.0.1.
IP Subnet
Mask
Enter the IP subnet mask of your switch in dotted decimal notation for example
255.255.255.0.
Default
Gateway
Enter the IP address of the default outgoing gateway in dotted decimal notation, for
example 192.168.0.254
Apply Click Apply to save the settings.
IP Interface
Index This field displays the index number of an entry.
IP Address This field displays IP address of the switch in the IP domain.
Subnet Mask This field displays the subnet mask of the switch in the IP domain.
VID This field displays the VLAN identification number of the IP domain on the switch.
Add Click Add to configure a new IP interface.
Modify Click Modify to change the settings of a selected IP interface.
Delete Click Delete to remove a selected IP interface.
