NetAtlas Workgroup Ethernet Switch Manager User’s Guide
173 Chapter 18 IP Configuration
Figure 122 IP Configuration: DVMRP
The following table describes the labels in this screen.
18.5 DHCP
DHCP (Dynamic Host Configuration Protocol RFC 2131 and RFC 2132) allows individual
computers to obtain TCP/IP configuration at start-up from a server. You can configure the
switch as a DHCP server or disable it. When configured as a server, the switch provides the
TCP/IP configuration for the clients. If you disable the DHCP service, you must have another
DHCP server on your LAN, or else the computer must be manually configured.
Table 92 IP Configuration: DVMRP
LABEL DESCRIPTION
Active Select Active to enable DVMRP on the switch. You should do this if you want the switch to
act as a multicast router.
Threshold Threshold is the maximum time to live (TTL) value. TTL is used to limit the scope of
multicasting. You should reduce this value if you do not wish to flood Layer 3 devices many
hops away with multicast traffic. This applies only to multicast traffic this switch sends out.
Index Index is the DVMRP configuration for the IP routing domain defined under Network. The
maximum number of DVMRP configurations allowed is the maximum number of IP routing
domains allowed on the switch. See Section 13.6 on page 116 for more information on IP
routing domains.
Network This is the IP routing domain IP address and subnet mask you set up in IP Setup.
VID DVMRP cannot be enabled on the same VLAN group across different IP routing domains,
that is, you cannot have duplicate VIDs for different DVMRP configurations.
Active Select Yes to enable DVMRP on this IP routing domain. Select No to disable this feature.
Apply Click Apply to save these changes.
