NetAtlas Workgroup Ethernet Switch Manager User’s Guide

Chapter 14 Switch Configuration

120

C

H A P T E R

14

Switch Configuration

This chapter shows how to configure switch settings such as priority queuing, STP, link
aggregation and GARP timer.

14.1 Switch Setup

Use the switch setup screen to set a VLAN type, a queuing method and enable or disable
features in the Active Control panel.

1 In the Device Panel list, select a device and then right-click.

2 Click Configuration > Switch Configuration > Switch Setup.

Figure 79 Switch Configuration: Switch Setup
