NetAtlas Workgroup Ethernet Switch Manager User’s Guide
121 Chapter 14 Switch Configuration
The following table describes the related labels in the screen.
Table 53 Switch Configuration: Switch Setup
LABEL DESCRIPTION
VLAN Type Choose 802.1Q or Port Based from the drop-down list box. The VLAN
Setup screen changes depending on whether you choose 802.1Q or Port
Based VLAN type in this screen. See Section 16.3 on page 142 and the
VLAN chapter for more information on VLANs.
MAC Address Aging Time MAC address learning reduces outgoing traffic broadcasts. For MAC
address learning to occur on a port, the port must be active.
Enter a time from 10 to 3000 seconds. This is how long all dynamically
learned MAC addresses remain in the MAC address table before they age
out (and must be relearned).
Queuing Method Select a queuing method. Choices vary depending on your switch models.
Strict Priority Queuing (SPQ) services queues based on priority only.
When the highest priority queue empties, traffic on the next highest-priority
queue begins. The default queuing method is Strictly Priority.
Weighted Round Robin Scheduling (WRR) services queues on a
rotating basis based on their queue weight (the number you select from
the drop-down list box for the corresponding queue). Queues with larger
weights get more service than queues with smaller weights.
Weighted Fair Scheduling is used to guarantee each queue's minimum
bandwidth based on their bandwidth portion (weight) (the number you
configure in the Weight field). Queues with larger weights get more
guaranteed bandwidth than queues with smaller weights.
Broadcast Storm Control These fields are not available on all switch models.
Set the fields below to configure traffic storm control.
Active Select Active to enable traffic storm control on the switch.
Storm Control Specify the traffic type in this field. Select Broadcast Only, Broadcast
and multicast, Broadcast and unknown unicast or Broadcast,
multicast and unknown unicast from the drop-down list box.
Packet Limit From the drop-down list box, select the number of packets (of the type
chosen above) a port can receive per second.
Active Control
STP Configuration Select the check box to activate STP.
Link Aggregation Select the check box to activate link aggregation.
IGMP Snooping Select the check box to enable IGMP snooping.
Bridge control protocol
transparency
Select the check box to enable bridge control protocol transparency.
Bandwidth control Select the check box to activate bandwidth control.
Broadcast storm
control
Select the check box to activate broadcast storm control.
Mirroring Select the check box to activate port mirroring.
802.1x Select the check box to activate IEEE 802.1x authentication.
Port Security Select the check box to activate port security.
