NetAtlas Workgroup Ethernet Switch Manager User’s Guide
Appendix A 190
Selection Tool
If you can’t see the selection tool, click View, Selection Tool to display it. Use the selection
tool to manipulate objects from one of several databases. Use the drag control at the right of
the selection tool to change its size. Select one of the selection tool tabs to display a tree
control for the database. Right-click on an icon inside a selection tree for database-specific
commands.
Event Log Tool
The event log tool displays different filtered views of the SNMPc event log. If you can’t see
the event log tool, click View, Event Log Tool to display it.
• Select the Current tab to show unacknowledged (current) events. These events have a
colored box at the left side of the log entry. The color of map objects is determined by the
highest priority unacknowledged event for that object.
• Select the History tab to show all events, including acknowledged and unacknowledged
events.
• Select one of the Custom tabs and use the right-click Filter View menu to specify what
events should be displayed for that tab.
• Double-click an event entry to display a Map View window with the corresponding
device icon visible.
• To quickly view events for a particular device, first select the device and then use one of
the View Events buttons (or the View, Active Events and View, History Events
menus). This will show the device events in a separate window in the View Windows
area.
• To remove one or more events, select the events and click the Delete key.
• To acknowledge (remove current status of) an event, right-click on an event entry and
click Acknowledge.
• To completely clear the event log, click File and Clear Events.
Table 106 Selection Tool
TAB DESCRIPTION
Map Map Object database, including devices and subnets.
Mib Compiled SNMP Mibs, Custom Tables and Custom Mib Expressions.
Trend Report profiles that define long-term polling procedures and scheduled reports.
Event Event filters used to determine what happens when an event is received.
Menu Custom menus that appear in the Manage, Tools and Help SNMPc menus.
