NetAtlas Workgroup Ethernet Switch Manager User’s Guide
Chapter 5 View 58
5.5.2 ARP Table
Address Resolution Protocol (ARP) is a protocol for mapping an Internet Protocol address (IP
address) to a physical machine address, also known as a Media Access Control or MAC
address, on the local area network.
Follow the steps below to view the ARP table.
1 Click View > 802.1d.
2 To view the ARP table of a switch choose a switch from the list located on the left-hand
side of the screen.
3 Click the ARP Table tab.
Figure 26 View: 802.1d: ARP Table
VID This is the VLAN group to which this MAC address belongs.
Port This is the port from which the above MAC address was learned.
Type This shows whether the MAC address is dynamic (learned by the switch) or static
(manually entered in the Static MAC Forwarding screen).
Polling The text box displays how often (in seconds) this screen refreshes. You may
change the refresh interval by typing a new number in the text box and then
clicking the Apply button.
Close Click Close to close the screen.
Table 22 View: 802.1d: MAC Table (continued)
LABEL DESCRIPTION
