NetAtlas Workgroup Ethernet Switch Manager User’s Guide
Chapter 16 Ethernet Port Configuration 142
16.3 Port VLAN
Follow the steps below to configure the Port VLAN screen.
1 In the Device Panel list, select a device and then right-click.
2 Click Configuration > Ethernet Port Configuration > Port VLAN.
3 Select a device and the port(s) to which you want to apply this configuration.
Figure 94 Ethernet Port Configuration: Port VLAN
BPDU Control Configure the way to treat BPDUs received on this port. You must activate bridging
control protocol transparency in the Switch Setup screen first.
Select Peer to process any BPDU (Bridge Protocol Data Units) received on this port.
Select Tunnel to forward BPDUs received on this port.
Select Discard to drop any BPDU received on this port.
Select Network to process a BPDU with no VLAN tag and forward a tagged BPDU.
Apply Click Apply to save your changes.
Table 69 Ethernet Port Configuration: Port Setup (continued)
LABEL DESCRIPTION
