NetAtlas Workgroup Ethernet Switch Manager User’s Guide
Chapter 3 EMS Main Window 38
If an alarm turns on, click the Port Status tab in the System Message Panel or proceed to
Section 5.1 on page 50 for hardware troubleshooting.
3.4 System Message Panel Port Status
Proceed to Section 5.4 on page 55 for information on the details displayed in this screen.
3.5 Menu Shortcut Buttons
The following is a brief overview of the menu shortcut buttons.
Figure 11 EMS Main Screen Shortcut Bar
3.6 EMS Main Menu Summary
This is a summary of the EMS menus in the main screen.
Note: Screens, screen labels and fields vary depending on your switch model.
TEMP When this icon is gray out,
temperatures at all sensor
points in the switch are within
the threshold temperature
range.
The temperature at a sensor
point in the switch has risen
above or below the threshold
temperature range.
VOL When this icon is gray out, the
power supply at all sensor
points in the switch is within
the tolerance range.
The power supply at a sensor
point in the switch has fallen
out of the tolerance range.
Table 10 System Message Panel Alarm Status (continued)
PANEL ALARMS ALARM OFF ALARM ON
Add Submap/
Device Find Object
Delete Submap/
Device
Interface
Performance
Refresh Map Port Status
Event Log
