NetAtlas Workgroup Ethernet Switch Manager User’s Guide
Chapter 13 System Configuration 116
The following table describes the labels in this screen.
13.6 IP Setup
Use the IP Setup screen to configure the default gateway device, the default domain name
server and add IP domains.
1 In the Device Panel list, select a device and then right-click.
2 Click Configuration > System Configuration > IP Setup.
Figure 77 System Configuration: IP Setup
Table 50 System Configuration: RADIUS
LABEL DESCRIPTION
Authentication Server
IP Address Enter the IP address of the external RADIUS server in dotted decimal
notation.
UDP Port The default port of the RADIUS server for authentication is 1812. You need
not change this value unless your network administrator instructs you to do
so.
Shared Secret Specify a password (up to 32 alphanumeric characters) as the key to be
shared between the external RADIUS server and the switch. This key is not
sent over the network. This key must be the same on the external RADIUS
server and the switch.
Apply Click Apply to save your changes.
