NetAtlas Workgroup Ethernet Switch Manager User’s Guide
169 Chapter 18 IP Configuration
18.2.5 Configuring a New OSPF Virtual Link
Follow the steps below to create a new OSPF virtual link.
1 In the Device Panel list, right-click on a device.
2 Click Configuration > IP Configuration > OSPF.
3 Click Add in the Virtual Link pane.
Figure 119 IP Configuration: OSPF: New Virtual Link
The following table describes the labels in this screen.
Default Route
Cost
Specify a cost (between 0 and 16777214) used to add a default route into a stub area
for routes which are external to an OSPF domain. If you do not set a route cost, no
default route is added.
Add Click Add to apply the changes and close this screen.
Cancel Click Cancel to discard all changes and close this screen.
Table 88 IP Configuration: OSPF: New OSPF Setting (continued)
LABEL DESCRIPTION
Table 89 IP Configuration: OSPF: New Virtual Link
LABEL DESCRIPTION
Name Enter a descriptive name (up to 32 printable ASCII characters) for identification
purposes.
Area ID Select the area ID (that uses the format of an IP address in dotted decimal
notation) of an area to associate the interface to that area.
Peer Router ID Enter the ID of a peer border router.
