E6581381
F-3
6
Output frequency [Hz]
Time [s]
Designated frequency − H
ON
OFF
Designated frequency + H
Designated frequency
Set frequency speed reach signal
RY-RC
FLA/FLC/FLB
Set frquency spped reach signal:
Inverted ON
OFF
0
6.1.3 Output of set frequency speed reach signal
H : Speed reach setting frequency
H : Speed reach detection band
• Function
When the output frequency becomes equal to the frequency set by H ± H, an ON or
OFF signal is generated.
[Parameter setting]
Title Function Adjustment range Default setting
H Speed reach setting frequency 0.0 ∼ HJ (Hz) 0.0
H Speed reach detection band 0.0 ∼ HJ (Hz) 2.5
[Parameter setting]
Title Function Adjustment range Setting value
H
Output terminal
selection 1A
(RY-RC)
0-255
(
⇒ See page K-17)
8: RCHF (designated frequency - ON
signal), or
9: RCHFN (designated frequency -
OFF signal)
Note: Select the H parameter function No. 8 or 9 to specify FLA-FLC-FLB terminal output.
