E6581381
K-14
11
• PM motor parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H 0910 Step-out detection
current level %
(A)
1/1 10-150 100
H 0911 Step-out detection
time s 0.1/0.1 0.0: No detection
0.1-25.0 0.0
H 0912 High-speed torque
adjustment
coefficient - 0.01/0.01 0.00-650.0 0.00
6.23
■ Default settings by inverter rating
Acceleration
Deceleration
time
Torque
boost value
1/2
PWM
carrier
frequency
Automatic
torgue
boost
value
Motor
rated
current
Motor
no-load
current
Motor rated speed
Motor
adjustment
coefficient
Display unit
selection for
integral
output power
H (min-1)
Inverter type
CEE , FGE,
H ,
H
XD /H
(%)
H
(kHz)
H
(%)
H
(A)
H
(%)
WN/V[R: 2 WP/V[R: 1
H H
VFFS1-2004PM 10 6.0 12.0 6.2 2.0 65 1680 1400 90 0
VFFS1-2007PM 10 6.0 12.0 5.8 3.4 60 1690 1408 80 0
VFFS1-2015PM 10 6.0 12.0 4.3 6.2 55 1690 1408 70 0
VFFS1-2022PM 10 5.0 12.0 4.1 8.9 52 1680 1400 70 0
VFFS1-2037PM 10 5.0 12.0 3.4 14.8 48 1690 1408 70 1
VFFS1-2055PM 10 4.0 12.0 3.0 21.0 46 1730 1441 70 1
VFFS1-2075PM 10 3.0 12.0 2.5 28.2 43 1730 1441 70 1
VFFS1-2110PM 10 2.0 12.0 2.3 40.6 41 1730 1441 60 1
VFFS1-2150PM 10 2.0 12.0 2.0 54.6 38 1730 1441 50 1
VFFS1-2185PM 30 2.0 8.0 2.0 68.0 36 1750 1458 50 1
VFFS1-2220PM 30 2.0 8.0 1.8 80.0 34 1750 1458 50 1
VFFS1-2300PM 30 2.0 8.0 1.8 108.0 32 1745 1454 50 1
VFFS1-4004PL 10 6.0 12.0 6.2 1.0 65 1680 1400 90 0
VFFS1-4007PL 10 6.0 12.0 5.8 1.7 60 1690 1408 80 0
VFFS1-4015PL 10 6.0 12.0 4.3 3.1 55 1690 1408 70 0
VFFS1-4022PL 10 5.0 12.0 4.1 4.5 52 1680 1400 70 0
VFFS1-4037PL 10 5.0 12.0 3.4 7.4 48 1690 1408 70 1
VFFS1-4055PL 10 4.0 12.0 2.6 10.5 46 1730 1441 70 1
VFFS1-4075PL 10 3.0 12.0 2.3 14.1 43 1730 1441 70 1
VFFS1-4110PL 10 2.0 12.0 2.2 20.3 41 1730 1441 60 1
VFFS1-4150PL 10 2.0 12.0 1.9 27.3 38 1730 1441 50 1
VFFS1-4185PL 30 2.0 8.0 1.9 34.0 36 1750 1458 50 1
VFFS1-4220PL 30 2.0 8.0 1.8 40.0 34 1750 1458 50 1
VFFS1-4300PL 30 2.0 8.0 1.8 54.0 32 1745 1454 50 1
