E6581381
F-80
6
Title Function Adjustment range Default setting
H
Operation at communication error
by disconnection
0:Inverter stop, communication
command, frequency mode open
(by EOQF, HOQF)
1:None (continued operation)
2:Deceleration stop
3:Coast stop
4:Communication error (GTT
trip) or Network error (GTT trip) 4
H
Number of motor poles for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
H Block write data 1 0
H Block write data 2
0: No selection
1: Command 1
2: Command 2
3: Frequency command
4: Output data on the terminal
board
5: Analog output for
communications
6: Motor speed command
0
H Block read data 1 0
H Block read data 2 0
H Block read data 3 0
H Block read data 4 0
H Block read data 5
0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VIA terminal board monitor
10: VIB terminal board monitor
11: Output motor speed monitor
0
H Free notes 0-65535 0
* Disabled............ Indicates that the inverter will not be tripped even if a communication error occurs.
Trip .................. The inverter trips when a communication time-over occurs.
In this case a trip information GTT flashes on and off on the operation panel.
