Key operated LED display Operation
W
Press the ENT key to enable the user parameter automatic edit
function.
or
WH
(WT)
↓
CEE
Searches for parameters that are different in value from the standard
default setting and displays those parameters. Press the ENT key or
the key to change the parameter displayed. (Pressing the key
moves the search in the reverse direction).
Press the ENT key to display the set value.
Press the key and key to change set value.
⇔CEE
Press the ENT key to save the changed value. The parameter name
and the programmed value will flash on and off alternately.
After the change has been saved, “W“ is displayed.
( ) WH
(WT)
Use the same steps as those given above to display parameters that
you want to search for or change setting with the key and key.
( ) ITW When IT. W appears again, the search is ended.
ITW
↓
HTH
↓
A search can be canceled by pressing the MODE key. Press the
MODE key once while the search is underway to return to the display
of parameter setting mode.
After that you can press the MODE key to return to the status
monitor mode or the standard monitor mode (display of operation
frequency).
If there is anything you do not understand during this operation, press the key several times to
start over from the step of CWHdisplay.
4.2.4 Setting a parameter, using the wizard function (CWH)
Wizard function (CWH):
The wizard function refers to the special function of calling up ten frequently used parameters.
You can set up the inverter easily by simply setting the parameters in one after another.
Notes on operation
• If there is anything you do not understand during this operation, press the key several times to
start over from the step of CWH display.
JGCF
or GPF is affixed respectively to the first or last parameter.
[Parameter setting]
Title Function Adjustment range Default setting
CWH Wizard function
The wizard function refers to the
special function of calling up ten
frequently used parameters.
-
MODE
ENT
ENT
ENT
ENT
MODE
MODE
MODE
