E6581381
F-5
6
6.3 Terminal function selection
6.3.1 Keeping an input terminal function always active (ON)
H : Always-active function selection 1
H : Always-active function selection 2
• Function
This parameter specifies an input terminal function that is always to be kept active (ON).
[Parameter setting]
Title Function Adjustment range Default setting
H Always-active function selection 1 0-71 ( ⇒ See page K-15) 0 (No function)
H Always-active function selection 2 0-71 ( ⇒ See page K-15) 1 (Standby)
* Coast stop
The standard default setting is for deceleration stop.
To make a coast stop, assign a "1(ST)" terminal
function to an idle terminal using the programmable
terminal function.
Change to
H=.
For coast stop, OFF the ST terminal when stopping
the motor in the state described at left.The monitor on
the inverter at this time will display QHH.
Motor
speed
ON
OFF
ON
OFF
F terminal
ST terminal
Coast stop
6.3.2 Modifying input terminal functions
H : Input terminal selection 1 (F)
H : Input terminal selection 2 (R)
H : Input terminal selection 3 (RES)
H : Input terminal selection 8 (VIA)
