E6581381
K-19
11
■ Table of output terminal functions 3
Function
No.
Code Function Action
53 PIDFN Inversion of signal in accordance of frequency
command (VIA) Inversion of PIDF setting
54 MOFF Undervoltage detection ON: Undervoltage detected
OFF: Other than undervoltage
55 MOFFN Inversion of undervoltage detection Inversion of MOFF
56 LOC Local/remote switching ON: Local mode
OFF: Remote mode
57 LOCN Inversion of local/remote switching Inversion of LOC
58 PTC PTC thermal alarm ON: 60% and over the protection level by PTC
OFF: Normal condition
59 PTCN Inversion of PTC thermal alarm Inversion of PTC
60 PIDFB Signal in accordance of frequency command (VIB) ON: Frequency commanded by HOQF or
H and that by VIB show the same
value.
OFF: Frequency commanded by HOQF or
H and that by VIB show different
values.
61 PIDFBN Inversion of signal in accordance of frequency
command (VIB) Inversion of PIDFB setting
62-253 Disabled Invalid settings, always OFF (ignored) Invalid settings, always OFF (ignored)
254 AOFF Always OFF Always OFF
255 AON Always ON Always ON
