E6581381
K-5
11
• Frequency parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: HOQF (Switchable to H by
terminal input)
H 0200 Frequency priority
selection - -
1: HOQF (Switchable to H at
less than 1.0Hz of designated
frequency)
0 6.5.1
7.1
H 0201 VIA input point 1
setting % 1/1 0-100 0
H 0202 VIA input point 1
frequency Hz 0.1/0.01 0.0-200.0 0.0
H 0203 VIA input point 2
setting % 1/1 0-100 100
H 0204 VIA input point 2
frequency Hz 0.1/0.01 0.0-200.0 50.0 (WP)
60.0 (WN)
6.5.2
H 0207 Frequency setting
mode
selection 2 - - 1: VIA
2: VIB
3: Operation panel
4: Serial communication
5: UP/DOWN from external contact 2 6.3.5
6.5.1
7.1
H 0210 VIB input point 1
setting % 1/1 0-100 0
H 0211 VIB input point 1
frequency Hz 0.1/0.01 0.0-200.0 0.0
H 0212 VIB input point 2
setting % 1/1 0-100 100
H 0213 VIB input point 2
frequency Hz 0.1/0.01 0.0-200.0 50.0 (WP)
60.0 (WN)
6.5.2
H 0240 Starting frequency
setting Hz 0.1/0.01 0.5-10.0 0.5 6.6.1
H 0241 Operation starting
frequency Hz 0.1/0.01 0.0-HJ 0.0 6.6.2
H 0242 Operation starting
frequency
hysteresis Hz 0.1/0.01 0.0-HJ 0.0
H 0250 DC braking
starting frequency Hz 0.1/0.01 0.0-HJ 0.0
H 0251 DC braking
current %(A) 1/1 0-100 50
H 0252 DC braking time s 0.1/0.1 0.0-20.0 1.0
6.7.1
H 0256 Auto-stop in case
of lower-limit
frequency
continuous
operation time s 0.1/0.1 0.0: Disabled
0.1-600.0 0.0 6.8
H 0264 External contact
input - UP
response time s 0.1/0.1 0.0-10.0 0.1
H 0265 External contact
input - UP
frequency steps Hz 0.1/0.01 0.0-HJ 0.1
6.5.3
